Technical Specifications
| S128-V1 Series LiFePO4 Battery 12.8V 100Ah–314Ah | ||||
| Specification | S128-100-V1 | S128-205-V1 | S128-300-V1 | S128-314-V1 |
| Rated Capacity | 100Ah | 205Ah | 300Ah | 314Ah |
| Energy Storage | 1280Wh | 2624Wh | 3840Wh | 4019Wh |
| Rated Voltage | 12.8V | 12.8V | 12.8V | 12.8V |
| Voltage Range | 10.8V–14.6V | 10.8V–14.6V | 10.8V–14.6V | 10.8V–14.6V |
| Max. Charge Current | 100A | 150A | 150A | 150A |
| Max. Discharge Current | 100A | 150A | 150A | 150A |
| Discharge Cut-off Voltage | 10.8V | 10.8V | 10.8V | 10.8V |
| Floating Voltage | 14.4V | 14.4V | 14.4V | 14.4V |
| Cycle Life | 6000 cycles @ 80% DOD | 6000 cycles @ 80% DOD | 6000 cycles @ 80% DOD | 6000 cycles @ 80% DOD |
| Certification | UN38.3 / MSDS | UN38.3 / MSDS | UN38.3 / MSDS | UN38.3 / MSDS |
| Working Temperature | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C |
| Mechanical & Logistics Data | ||||
| Product Dimensions (L×W×H, mm) | 328×213×101 mm | 229×185.2×330 mm | 358×308×154 mm | 358×308×154 mm |
| Net Weight (kg) | 10 kg | 21 kg | 26 kg | 27.5 kg |
| Package Dimensions (L×W×H, mm) | 391×252×174 mm | 295×251×353 mm | 426×344×225 mm | 426×344×225 mm |
| Gross Weight (kg) | 10.9 kg | 21.5 kg | 27.5 kg | 29 kg |
| Freight calculation should use Package Dimensions and Gross Weight. Verified size/weight data is not present in the supplied website, product catalog or user manual. | ||||
| Website Feature / General Parameter Notes | ||||
| Integrated BMS | Yes | |||
| Cell Type | A-Grade LiFePO4 | |||
| Display | LCD Display | |||
| Charge / Discharge | Up to 150A, model dependent | |||
| Recommended Applications | Solar storage / backup power / off-grid applications | |||
