INVERTER
|
BATTERY
|
Model
|
TURBO-2000-12
|
Battery Chemistry
|
LiFePO4
|
Battery System Voltage
|
12VDC
|
Rated Voltage
|
12.8V
|
Rated Power
|
2000VA / 2000W
|
Capacity Options
|
100Ah / 150Ah / 205Ah / 300Ah / 314Ah
|
Surge Power
|
4000W
|
Energy Range
|
1.28kWh–4.019kWh
|
Waveform
|
Pure sine wave
|
Voltage Range
|
10.8V–14.6V
|
AC Output
|
230VAC ±5%
|
Max Charge Current
|
100A (100Ah/150Ah); 150A (205Ah/300Ah/314Ah)
|
Peak Efficiency
|
93%
|
Max Discharge Current
|
100A (100Ah/150Ah); 150A (205Ah/300Ah/314Ah)
|
Solar Charger Type
|
MPPT
|
Floating Voltage
|
14.4V
|
Max PV Array Power
|
3000W
|
Cycle Life
|
6000 cycles @ 80% DOD
|
Max PV Open Circuit Voltage
|
500VDC
|
Certification
|
UN38.3 / MSDS
|
Max PV Input Current
|
18A
|
Operating Temperature
|
-20°C to 55°C
|
MPPT Voltage Range
|
60–450VDC
|
|
|
Max Solar Charge Current
|
100A
|
|
|
Max AC Charge Current
|
80A
|
|
|
Maximum Charge Current
|
100A
|
|
|
Dimensions
|
500 × 326 × 100 mm
|
|
|
Net Weight
|
10 kg
|
|
|
Protection Degree
|
IP55
|
|
|
Operating Temperature
|
-16°C to 50°C
|
|
|
Warranty
|
2 Years
|
|
|
